Expandable shipping container house

Applications:

Disaster Relief	Site Office
Accommodation	Clinic
Classroom	Storage
Emergency Function	Outdoor Cafe

Inquire Now

Description Specifications Features Applications

Description

Expandable shipping container house has super convenience, after finishing lifting, move directly from one place to another. Of course, the installation is also time-saving and labor-saving. The container home features with the expandable installation, one house can be installed by the crane with five steps. There are two different designs for the expandable container house: type A inside empty, type B with two bedrooms, one toilet, one kitchen and one living room.

The self-weight of the expandable container house is more than 2 tons. It is composed of light steel structure and color steel sandwich panel. The wind pressure resistance is 90~110Km/h, and the earthquake resistance is >8 grade. It is used under the temperature of -40 degrees, and the indoor temperature is normal. It has super thermal insulation, which comes from the external wall insulation material. The polyurethane insulation layer used has a thermal conductivity of only 0.018~0.024w/(m.k). The house structure is composed of galvanized light steel structure, which has super moisture resistance and termite resistance, and is suitable for living in humid areas.

Specifications of Expandable Movable Detachable Container Houses

External Size(mm): W6320*L5900*H2480 (lower side 2270)

Internal Size(mm): W6240*L5380*H2280 (lower side 2150)

Folded Size(mm): W2160*L5900*H2480

Wall Panel: 75mm EPS sandwich/Rock wool panel

Inside wall: 50mm EPS sandwich/Rock wool panel

Bathroom: Washing cabinet set with mirror+ceramic washbasin+ceramic toilet+Integral shower room, water supply pipe ppr, drainage pipe pvc.

Kitchen: High-density particle board kitchen cabinet with sink

Door: Bridge-cut aluminum alloy frame door with double layers tempered glass.

Tiny Expandable Prefab Container House Features

Prefabricated construction

Precision manufacturing ensures high-quality construction with minimal on-site work. Reduced construction time compared to traditional methods, enabling quicker occupancy. Environmentally friendly with less waste and energy consumption during the building process.

Portability

Modular design allows easy disassembly and transportation to different locations. Lightweight materials ensure hassle-free relocation using standard transportation methods. Quick and efficient setup at various sites, providing flexibility and mobility.

Amenities and Features

Large windows and skylights for abundant natural light. Spacious bedrooms, bathrooms, and living areas for a comfortable lifestyle. High-tech security systems and home automation for safety and convenience.

Convenient disassembly

(4)Convenient disassembly, superior performance, stable and firm, good shock performance, waterproof, fire and corrosion prevention, light weight, the expandable prefab container house is the overall structure, there is a frame, the wall is a steel plate, the wood veneer can be used, the whole migration, the service life can reach more than 20 years.

Applications of Customized Expandable Tiny Container House

This prefab expandable container house is very convenient for transportation, moving by truck. It can be assembled and disassembled for more than 20 times. So the mobile expandable container house is popularly used in military camp and field.

Such portable container houses can also be commonly used for disaster relief, site office, accommodation, clinic, classroom, storage, emergency function, outdoor cafe, etc.
